The release of the Black Cat Dimmer is due end of August.
It features smooth dimming control over dimmable LED Lights either by using manual switching or Z-Wave technology.
Tested in both HomeSeer and Vera environments, it is an inexpensive control device suited to today's modern home environment.
Switching can be controlled by either a single switch or a up/down momentary switch such as a TEM PW-1D.
Further Specifications include:
Input Rating:(Operating Voltage) 100-240Vac / 50Hz-60Hz
Input Rating:(Operating Current) 0.01~1A ; (Maximum: 1A)
Output Rating: Maximum Load (Current) Maximum: 0.9A (100-240Vac)
Output Rating: Maximum Load (watts)(230V)
200W (13W x 15 pieces) (Dimmable LED bulbs) (230Vac)
Output Rating: Maximum Load (watts)(120V)
100W (13W x 15 pieces) (Dimmable LED bulbs) (120Vac)
Output Rating: Maximum Dimmable LED bulbs
Maximum: 15 pieces (Dimmable LED bulbs)
Operating Temperature 0°C ~ 40°C
Frequency Range 921.40/921.42mHz.
RF Maximum Power +5dBm
Transmission Range Minimum 40 m in door 100m outdoor line of sight
Modulation Type FSK (Frequency-Shift Keying)
